Description
10B-3 roller chain is a 15.875mm pitch triplex (triple-strand) metric roller chain made per ISO and British Standards. As a triple-strand roller chain, it is engineered to operate in demanding applications that other strand widths would be incapable of. What makes our 10B-3 roller chain special is the use of high-grade alloy and carbon steel materials per component and processes like heat-treating and shot peening done to each component before assembly. The chain is also factory pre-loaded to reduce significantly or eliminate initial and long-term elongation. Stacking up these features produces an 10B-3 chain that is more capable and has a superior lifespan than others available. This chain is supplied as a 10ft box, including one connecting link. We also provide 10B-3 roller chain sprockets and tools for making replacement or repairs easier. For additional information or to request a quote for our tier one 10B-3 chain, contact our customer service team, and we will be happy to assist you!
10B-3 Chain Dimensions
- Part #: 10B-3
- Pitch (P): 15.875mm
- Roller Width (R): 9.65mm
- Roller Diameter (D): 10.16mm
- Overall Width (W): 52.30mm
- Connecting Link Overall Width (X): 56.90mm
- Plate Height (H): 14.70mm
- Plate Thickness (T): 1.70mm
- Pin Diameter (L): 5.08mm
- Minimum Breaking Load: 6,870 KGS
- Weight: 2.8 kG/ m
