Description
7206 CT.P4.UL spindle bearing is manufactured by AXIS to extremely precise ABEC 7 precision tolerances for maximum precision when in operation. This 30x62x16 7206 CT.P4.UL spindle bearing utilizes top-grades of materials as well as proprietary engineering and manufacturing techniques to provide the best spindle bearing on the market. Additional configurations for spindle bearings include duplex, triplex, and quadplex pairs to meet the application requirements. The purpose of a spindle bearing is to enhance and streamline spindle movement to ensure optimal machine speed and accuracy, this AXIS 7206 CT.P4.UL spindle bearing executes this purpose with the utmost accuracy and precision. Common applications for spindle bearings include; machine tools, medical equipment, aerospace, textile applications, and more. To get a quote or for additional information contact our customer support team and we will be happy to assist you.
7206 CT.P4.UL Spindle Bearing Dimensions
- Bearing Size: 7206 CT.P4.UL
- Dimension (d): 30mm
- Dimension (D): 62mm
- Dimension (B): 16mm
- Dynamic Load Rating: 5463 LBS
- Static Load Rating: 3574 LBS
- Limiting Speed (Grease): 24000 RPM
- Limiting Speed (OIL): 38000 RPM
- Weight: 0.44 LBS
